KSMA+D Series Single Phase AC Output SSR

KSMA+D Series Single Phase AC Output SSR. KSMA series is a single-phase AC output solid state relay, which is designed to be pluggable into industry standard relay sockets to replace plug-in electromechanical relays. They are available with ratings from 1 to 2 Amps at 24 to 280VAC. This is an UL and TUV recognized and CE compliant product.


Send Inquiry

Product Description

KSMA+D Series Single Phase AC Output SSR
· Optocoupler Isolation
· TRIAC Output
· Load Voltage: 240VAC
· Load Current:1A,2A
· Dielectric Strength 2500VACrms
· PCB or Socket Mounted
· RoHS Compliant

General parameters

Name KSMA Series SSR
Load Voltage 240VDC
Load Current 1A / 2A
Ambient Temperature Range -30℃ ~ +80℃
Storage Temperature Range -30℃ ~ +100℃
Weight (Typical) 4g

Click the link below to download datasheet


General Notes

1. At 260℃ welding temperature, the whole process cannot exceed 10 seconds; the welding process cannot exceed 5 seconds at 350℃.
2. When the ambient temperature of the product operation is high, please consider the derating as per the thermal curve.
3.The installation torque recommended for the socket connection is 0.5N·m.
4. The control terminal polarity should be correct; otherwise the product may be damaged.

◆Product specifications are subject to change without notice. Please don’t hesitate to contact with us for any technical questions.
